PowerBox Digi-Switch V2 MPX/JR

6432

New product

The PowerBox DigiSwitch V2 is the second generation of the PowerBox Digi-Switch, which is well-known throughout the world.

More details

By buying this product you can collect up to 5 loyalty points.


In stock

55,00 €

Price excluding taxes : 45,83 €
VAT : 9,17 €

Delivery service

Logo de service de livraison

Payment methods

Logo de solutions de paiement

The PowerBox DigiSwitch V2 is the second generation of the PowerBox Digi-Switch, which is well-known throughout the world.

Features

  • High-performance electronic switch
  • Ultra-light unit, compact format
  • Regulated output voltage
  • User-selectable output voltage: 6.0 V/7.0 V/7.6 V or non regulated
  • RGB LED voltage indicator for the battery
  • Telemetry support for CORE systems
  • Supports 4 different battery types: 2s LiPo, 2s LiIon, 2s LiFePo and 5s NiMH
  • Regulator monitoring
  • Suppression of servo feedback currents

Technical Data

Operating voltage 4.0V - 9.0V
Power supply 2s LiPo, 2s LiIon, 2s LiFePo, 5s NiMH
Current drain Power-on state 23 mA
Current drain Standby 4 μA
Maximum load current max. 10 A
Drop-out voltage 0.1 V
Output voltage 6.0 V/ 7.0 V/7.6 V stabilised or non-regulated
Dimensions 50 x 18 x 11 mm
Weight 15 g
Temperature range -30 °C to +75 °C
